TP-Link CPE710 5GHz AC867 23dBi Outdoor CPE

Description

The TP-Link CPE710 5GHz AC867 23dBi Outdoor CPE is a professional long-range wireless networking solution designed for point-to-point (PtP) and point-to-multipoint (PtMP) deployments. Featuring 867Mbps 802.11ac wireless speeds, a 23dBi high-gain directional antenna, Gigabit Ethernet, Pharos Control, and an IP65 weatherproof enclosure, it delivers stable, high-performance wireless connectivity over long distances for businesses, campuses, farms, warehouses, and ISPs.

Features OF TP-Link CPE710 5GHz

• Up to 867Mbps wireless speed on the 5GHz band
• 23dBi high-gain directional 2×2 MIMO antenna
• Designed for long-range point-to-point and point-to-multipoint links
• Gigabit Ethernet port for high-speed wired connectivity
• Qualcomm 750MHz processor for reliable performance
• Pharos Control centralized management software
• Built-in PharOS operating system
• IP65 weatherproof enclosure
• 15kV ESD and 6kV lightning protection
• Supports 24V Passive PoE for flexible installation
• Adjustable transmit power
• Pole-mount installation with durable wind-resistant design

Specifications

• Model: TP-Link CPE710
• Device Type: Outdoor Wireless CPE
• Wireless Standard: IEEE 802.11a/n/ac
• Wireless Speed: Up to 867Mbps
• Frequency: 5GHz (5.15–5.85GHz)
• Antenna: 23dBi Directional 2×2 MIMO
• Ethernet Port: 1 × Gigabit RJ45 Port
• Processor: Qualcomm 750MHz CPU
• Memory: 128MB DDR2 RAM
• Flash Storage: 16MB
• Power: 24V Passive PoE
• Weather Rating: IP65
• Protection: 15kV ESD, 6kV Lightning Protection
• Management: PharOS Web Interface, Pharos Control
• Mounting: Pole Mount

Uses of TP-Link CPE710 5GHz

• Long-distance point-to-point wireless bridges
• Point-to-multipoint wireless deployments
• Internet distribution for campuses
• Farm and agricultural connectivity
• Warehouse and factory networking
• CCTV surveillance backhaul
• ISP and WISP wireless deployments
• Connecting remote buildings without cabling

Summary

The TP-Link 5GHz AC867 23dBi Outdoor CPE is engineered for reliable long-distance wireless communication. Combining 867Mbps wireless performance, a 23dBi directional antenna, Gigabit Ethernet, Passive PoE, and a rugged IP65 weatherproof design, it provides an ideal solution for outdoor broadband links, surveillance systems, and enterprise wireless networking.
