Dell PowerEdge R760xs 2U Rack Server – Xeon Silver 4410Y, 16GB DDR5, PERC H755, Dual 700W PSU

Description

The Dell PowerEdge R760xs is a powerful 2U rack server designed for demanding business applications, virtualization, databases, data storage and enterprise IT infrastructure. This configuration features an Intel Xeon Silver 4410Y 12-core/24-thread processor, 16GB DDR5-5600 memory, an 8 × 3.5-inch drive chassis and PERC H755 RAID controller. With dual 700W power supplies, multiple Gigabit and 10GbE networking options, iDRAC9 Enterprise and 3-Year ProSupport, it provides a robust platform for professional server environments.

Key Features of Dell PowerEdge R760xs

• Intel Xeon Silver 4410Y processor
• 12 cores / 24 threads
• 2.0GHz processor speed
• 16GT/s Intel UPI
• 16GB DDR5-5600 RAM
• 8 × 3.5-inch drive chassis
• PERC H755 RAID controller
• Dual 700W power supplies
• Broadcom 5720 Dual-Port 1Gb onboard LOM
• Broadcom 5720 Quad-Port 1GbE BASE-T adapter
• Broadcom 57416 Dual-Port 10GbE BASE-T adapter
• OCP NIC 3.0 support
• PCIe low-profile expansion
• iDRAC9 Enterprise remote management
• 2U rackmount form factor
• ReadyRails sliding rails included
• 3-Year Dell ProSupport

Specifications

• Brand: Dell
• Series: PowerEdge
• Model: R760xs
• Product Type: 2U Rack Server
• Processor: Intel Xeon Silver 4410Y
• CPU: 12 cores / 24 threads
• UPI Speed: 16GT/s
• RAM: 16GB DDR5-5600
• Drive Chassis: 8 × 3.5-inch
• RAID Controller: Dell PERC H755
• Network: Broadcom 5720 Dual-Port 1Gb onboard LOM
• Additional Network: Broadcom 5720 Quad-Port 1GbE BASE-T
• 10GbE: Broadcom 57416 Dual-Port 10GbE BASE-T
• Network Expansion: OCP NIC 3.0
• Expansion: PCIe low-profile
• Remote Management: iDRAC9 Enterprise
• Power Supply: 2 × 700W PSU
• Rack Form Factor: 2U
• Rails: ReadyRails Sliding Rails without CMA
• Support: 3-Year Dell ProSupport
• Operating System: Configuration dependent

Ideal Uses of Dell PowerEdge R760xs

• Enterprise server infrastructure
• Virtualization
• Database hosting
• Business applications
• Centralized data storage
• File and application services
• Backup and disaster recovery
• High-speed network workloads
• Data-intensive business environments
• Multi-user enterprise applications

Summary

The Dell PowerEdge R760xs combines the Intel Xeon Silver 4410Y 12-core processor, 16GB DDR5-5600 RAM, PERC H755 RAID controller and 8 × 3.5-inch drive chassis in a scalable 2U rackmount platform. With dual 700W PSUs, 1GbE and 10GbE networking, iDRAC9 Enterprise and 3-Year ProSupport, it is built for reliable business-critical workloads and professional IT infrastructure.
